Key Features
- Protects aircraft from unwanted landings and batteries from over-discharging
- Programmable voltage threshold
- Ideal for all electric vehicles, boats, and aircraft using LiPo batteries
- Protects drivers from over-discharging LiPo's when using an ESC that doesn't have Low Voltage Cutoff
- Monitors a batteries low voltage down to the cell level
- Unit checks and displays the cell count, voltage of the overall pack and then each cell individually up to 8S
- Compatible with JST-XH type balance connectors
- Large, digital LED display
- High pitched low voltage warning buzzer
- Compatible with 1-8s Lipo/Li-ion/LiMn/Li-Fe
- Voltage detection precision to 0.01V
- Cell voltage display range: 0.5V-4.5V
- Pack voltage display range: 0.5V-36V
- Low voltage alarm mode for 2-8S
- Alarm set value range: OFF-2.7V-3.8V
- When the cell voltage is below the set value, the buzzer will sound along with red LED light, default value 3.3V
Field Equipment: Voltmeters Height: 0.35 in (9mm) Length: 1.53 in (39mm) Width: 0.94 in (24mm)
- Protects aircraft from unwanted landings and batteries from over-discharging
- Programmable voltage threshold
- Ideal for all electric vehicles, boats, and aircraft using LiPo batteries
- Protects drivers from over-discharging LiPo's when using an ESC that doesn't have Low Voltage Cutoff
- Monitors a batteries low voltage down to the cell level
- Unit checks and displays the cell count, voltage of the overall pack and then each cell individually up to 8S
- Compatible with JST-XH type balance connectors
- Large, digital LED display
- High pitched low voltage warning buzzer
- Compatible with 1-8s Lipo/Li-ion/LiMn/Li-Fe
- Voltage detection precision to 0.01V
- Cell voltage display range: 0.5V-4.5V
- Pack voltage display range: 0.5V-36V
- Low voltage alarm mode for 2-8S
- Alarm set value range: OFF-2.7V-3.8V
- When the cell voltage is below the set value, the buzzer will sound along with red LED light, default value 3.3V
Field Equipment: | Voltmeters |
Height: | 0.35 in (9mm) |
Length: | 1.53 in (39mm) |
Width: | 0.94 in (24mm) |
